Packaging

Motion that keeps the line moving.

Turnkey multi-axis systems and individual motion components for wrapping, boxing, bottling, and palletizing, from single stages to complete systems with drives, HIMC controllers, and custom programming.

Two robotic arms labeled HIWIN sort small black packages on a conveyor belt in an industrial setting with cardboard boxes and equipment in the background.

3–65mm

Linear guideway sizes, with ball or roller bearings

Turnkey

Stages, drives, and HIMC controller delivered as one programmed system

FDA

Food-grade coating options across guideways, screws, splines, and gearing

Applications

On every axis of the packaging line.

From the fill head to the palletizer, HIWIN stages and components carry the motion that wraps, boxes, and bottles the products on every shelf.

  • Filling & bottling

    Ballscrew and belt stages meter containers through fill lines at production speed.

  • Cartoning & case packing

    Multi-axis systems fold, load, and seal cartons with repeatable motion, cycle after cycle.

  • Pick-and-place

    Linear motor stages sustain high duty cycles for sorting and top-loading without losing placement accuracy.

  • Capping & closing

    Torque motors deliver the high angular acceleration and accuracy capping heads demand.

  • Labeling & registration

    Precise positioning keeps labels, dates, and codes exactly where retail compliance requires.

  • Food-grade lines

    Guideways, ballscrews, splines, and strain wave gearing with food-grade coatings meet FDA requirements.

A close-up of an industrial linear actuator displayed on a green and white shelf, with a square metallic body and visible mounting holes, used in automation or machinery applications.

Why HIWIN

Every packaging machine is custom-built. Your motion supplier should work that way too.

Every industry relies on packaging to protect products through their lifecycle: consumer goods, food and beverage, cosmetics, healthcare, industrial, military, and many others. And every packaging machine is custom-built to create a specific type of packaging, which means off-the-shelf motion rarely fits.

HIWIN is a premier supplier of turnkey systems for the packaging industry: multi-axis, linear, or combined linear-and-rotary solutions driven by ballscrew stages, belt stages, or linear motor stages for fast motion and very high duty cycles, supervised by HIMC controllers with custom programming. Or start from components and build your own: guideways from 3mm to 65mm, ballscrews, ball splines, and AC servo motors, for stages of any travel length and any load.

Products

Stages, components, and the controller that supervises them all.

Browse all products →
  • A black linear actuator with a lead screw mechanism and a stepper motor, featuring a sliding carriage on metal rails for precise motion control in automation or robotic applications.

    Filling · Cartoning · Case packing

    Ballscrew Stages

    Standard KK-series ballscrew stages driven by HIWIN AC servo motors, or custom stages of any travel length and load, built from HIWIN components.

    Browse ballscrew stages →
  • 3D-rendered image of a linear motion guide with an attached cable, featuring a black and silver design with colored accents, labeled HIWIN on one end, shown on a plain white background.

    Pick-and-place · High duty cycle

    Linear Motor Stages

    Fast linear motion on specific axes and very high duty-cycle operation, the stage of choice where packaging throughput is the constraint.

    Browse linear motor stages →
  • A linear guide rail with a metal carriage block mounted on a steel track, used for precise linear motion in machinery. The block has green and red end caps and mounting holes.

    Custom machine builds

    Linear Guideways

    The key component of custom packaging systems: every size from 3mm to 65mm, ball or roller bearings, angle guideways, and PG-series magnetic encoder options.

    Browse linear guideways →
  • A close-up of a cylindrical metal electric motor with grooved outer layers, a hollow center, and two wires—one black and one orange—extending from the side.

    Capping · Rotary motion

    Torque Motors

    Very high angular acceleration and accuracy for the rotary axes of the line: capping, indexing, and orienting product between stations.

    Browse torque motors →

Researching a design? Download catalogs and application notes →

Application Brief

What a multi-format line demands of its axes.

A filler-capper cell that runs more than one container format spends its life changing over. Every manual adjustment between runs is time the line is not producing and a chance to introduce error, so the motion has to be programmable rather than re-fixtured: axes that move to a new position on command and hold it. HIWIN supplies the whole chain for that kind of cell. Ballscrew stages drive filling axes, linear motor stages carry high-duty-cycle top-loading travel, and torque motors sit under capping heads, with a HIMC controller supervising them as one system. Food-grade coatings are available where the axis sits in a wash-down or contact zone.

A person wearing blue gloves uses a dial gauge to measure a metal threaded rods dimensions on a workbench, with a hand holding a red marker in the foreground.

KK series

Ballscrew stages for filling and indexing axes

LMSSA

Linear motor stages for high-duty-cycle travel

HIMC

Controller supervising the cell as one system

FAQ

Packaging motion control, answered.

Still weighing a design decision? Ask an application engineer →

Does HIWIN supply complete packaging motion systems or just components?

Both. HIWIN delivers turnkey packages (multiple motion stages, drives, and HIMC controllers with custom programming to supervise all axes) as well as individual components for customers who engineer and construct their own packaging machinery.

Are food-grade components available for food and beverage lines?

Yes. Crossed roller bearings, strain wave gearing systems, linear guideways, ballscrews, and ball splines are available with food-grade coatings to meet FDA requirements.

When should a packaging machine use linear motor stages instead of ballscrew stages?

Linear motor stages are the choice for high-speed motion on specific axes and very high duty-cycle operation: pick-and-place and top-loading at sustained line rates. Ballscrew and belt stages remain the economical choice for filling, cartoning, and case-packing axes.

What sizes of linear guideway does HIWIN offer for packaging machinery?

Every size from 3mm to 65mm, with ball bearings or roller bearings, plus angle linear guideways and guideways with embedded PG-series magnetic encoders for axes that need position feedback built in.

Who programs and supports the HIMC controller?

HIWIN can deliver the HIMC controller with custom programming as part of a turnkey package, and HIWIN application engineers offer training so your team can program and maintain it in-house.

A persons hands install a metal bearing onto a long, cylindrical metal rod in a workshop or industrial setting. Shelves and equipment appear blurred in the background.

Packaging

Speccing a packaging machine? Talk it through with an application engineer.
